In this article we'll go over how you can modify your domain's DNS records, in order to split up your various services between multiple hosting providers.

In most cases the average website owner will have all of their web services with one hosting provider. In some cases though you might want to split up your services, so that you have one provider actually host your website, and a completely separate provider to host your email.

In order to follow any of the steps below, you'll need to have your domain name pointed at our name servers, so that any DNS changes you make in cPanel on our server is what your domain actually uses.

Website hosted by 3rd party, email hosted by InMotion

A common example of this, is if you're using a website hosting company that has a proprietary website builder, but maybe doesn't host email. So if you looked for a new web host and found InMotion Hosting, your plan might be to slowly transition your website over to non-proprietary website software with us, and in the meantime also have us host your email for you.

In the steps below, we'll walk through using an example domain PrimaryDomain.com. Where we would like to continue to have the e-mail hosted by InMotion Hosting, but we want to point our DNS A (Address) record to another website host where you might already have your site built.

  1. Login to your cPanel
  2. click on advancedd dns zone editor Under the Domains section, click on Advanced DNS Editor
  3. select domain from drop down Select the domain you'd like to modify in the drop-down to see those DNS records.
  4. click on edit beside domain a record In this example the DNS records are already setup pointing the entire domain to InMotion's servers for all of the services. So the only thing we need to modify is our A (Address) of the website.

    Click on Edit beside the primarydomain.com. entry.

  5. fill in remote host ip address for website a record Fill in the IP address of your remote website host, in the Address field, then click on Edit Record.
  6. Anytime you make DNS changes, it can take between 24-48 hours for those DNS settings to fully propagate. So your website will not start immediately pulling from this new IP address, and it will take a different amount of time depending on several factors.

  7. delete mail cname recordYou should now see the new A record you updated. Now click on Delete beside the CNAME record for mail.primarydomain.com.
  8. add mail a recordUnder the Add a record section, now re-create the mail. CNAME record you deleted, but this time as an A record, and pointing to the InMotion server's IP address. You can always find your IP address in cPanel.
  9. click on mx entryAt the main cPanel page, under the Mail section click on MX Entry.
  10. click on edit mx recordUnder the MX Records section at the bottom, click on Edit beside your primarydomain.com entry with a Priority of 0.
  11. add mail to mx entry click editNow type in mail. in front of your domain to correlate your MX record with the local A record we previously created.
  12.

Website hosted by InMotion, email hosted by 3rd party

A common example of this, is if you'd like to host your website with InMotion Hosting, but you have email services with another provider such as Google Apps for your domain.

In the steps below, we'll walk through using an example domain PrimaryDomain.com. Where we would like to continue to have the website hosted by InMotion Hosting, but we want to point our DNS MX (Mail Exchange) record to another email host.

  1. Login to your cPanel
  2. click on mx entry Under the Mail section, click on MX Entry.
  3. In the Add New Record section, you'll want to set the Priority and Destination for your 3rd party mail service, then click on Add New Record.

    We are going to use Google's as an example, since they're very common:

    PriorityDestination
    1 ASPMX.L.GOOGLE.COM
    5 ALT1.ASPMX.L.GOOGLE.COM
    5 ALT2.ASPMX.L.GOOGLE.COM
    10 ASPMX2.GOOGLEMAIL.COM
    10 ASPMX3.GOOGLEMAIL.COM

    These should all now be populated in the MX Records section at the bottom.

  4. click on delete local mx recordWith all of the remote MX servers added, we now want to remove the original local one.

    Click on Delete beside the primarydomain.com. MX entry, then click the confirmation Delete button.

  5. click on remote mail exchanger Finally change the Email Routing option to Remote Mail Exchanger, then click on Change
  6. Anytime you make DNS changes, it can take between 24-48 hours for those DNS settings to fully propagate. So your email will not start immediately delivering to these new remote MX servers.

You should now understand how to split up your domain's various services by using DNS records. While this typically isn't needed for the average user, it might be good to know that you do have this option available to you.

Support Center Login

Social Media Login


Social Login Joomla

Related Questions

Here are a few questions related to this article that our customers have asked:
Ooops! It looks like there are no questions about this page.
Would you like to ask a question about this page? If so, click the button below!
Ask a Question
n/a Points
2014-06-04 6:48 am

I am configuring spilt delivery with Google and it was working fine. When I delete the CNAME record and create the A recod my hosted email with inmotionhosting no longer able to receive emails. Any suggestions please?

Staff
11,186 Points
2014-06-04 8:44 am
This is because the MX records which control mail point to the location of your A record by default which is then sending your mail to the other location that you changed your A record to. To fix it, you may use the MX Entry tool to point your mail to the server that you are located on. You may see this to the left side of cPanel and will say something like bizXXX.inmotionhosting.com.
n/a Points
2014-06-27 7:27 am

I really need help to setup this correctly, my setup as follows:

- Website hosted locally (Made the above steps)

- Have group of emails hosted in Google Apps

- Have the rest of the staff emails hosted in my Inmotion Hosting

--

So far things work, but now mail from Gapps/Inmotion to Group don't reach Inmotion-hosted accounts inside that group. Ex: When I send email to a group contain users from Gapps, Inmotion, hotmail, etc.. the message don't rach Inmotion accounts only!!

Any advise?! Thanks!

Staff
27,869 Points
2014-06-27 7:50 am
Hello Yousif,

Thank you for your question. We are happy to help, but will need some additional information.

Are the emails returned or bounced? If so, can you provide the returned/bounced message?

Also, it may be easier to contact live support at the time you are sending the emails. so they review the server logs in real-time.

If you have any further questions, feel free to post them below.
Thank you,

-John-Paul
n/a Points
2015-01-19 12:18 pm

Hello John,

No, there's no return emails. It went fine as it's delivered to end user without any sign of delivery failer.

n/a Points
2015-01-17 8:12 pm

Hello Yousif,

I am in a similar situation. How did you end up solving the issue please? I will love to hear from you.



Thanks



Staff
27,869 Points
2015-01-19 11:26 am
Hello Muhire,

Thank you for contacting us. If you want email hosted at 2 different places, you would have to setup 2 separate mail servers, and point their "A record" to different locations.

For example create:
mail1.example.com with an A record pointed to Google Apps.

mail2.example.com with an A record pointed to InMotion Hosting.

Then, people using Google apps use mail1.example.com as their mail server.

People with email hosted at InMotion will use mail2.example.com

If you have any further questions, feel free to post them below.

Thank you,
John-Paul
n/a Points
2015-01-19 12:16 pm

I handle it by creating an mail forwarder to every single Google App's email in inMotion cPanel

using the free offered test domain alias from Google.

Example: I have hr@mycompany.com hosted in Google Apps, so I created hr@mycompany.com.test-google-a.com in cPanel > Forwarders

So far everything working fine but groups!

Groups I created under Google Apps with users from:

Google Apps > Get emails of course. InMotion Hosting > Don't get emails! Other public services (Hotmail, outlook.com, yahoo,..) > Get emails.

n/a Points
2015-12-02 2:50 pm

I’m looking at the “Website hosted by Inmotion, email hosted by third party”, in your example the third party is Google Apps.I’m looking at this for my clients to protect them from losing email if Inmotion’s servers and their website go down, like happened recently. (bad day all round)

If I understand correctly the changes you are making in cPanel in the above example would not protect the email services as the message still needs to go to Inmotion’s servers to get the mail record.To get the separation I want I think I need to change the MX records at the domain registry, not Inmotion, and in that way website inquiries will go to the site hosted at Inmotion and email will go to Google Apps, for example. Each would function independently of each other.Am I correct?Thank you,ernie

Staff
37,430 Points
2015-12-02 3:46 pm
Hello Ernest,

The main difference we're talking about is how the DNS is being handled and specifically where it's being handled. MX records are part of the DNS. So, when something is emailed, the responding server first has to identify WHERE it's coming from. The DNS records (on the DNS server) provide this information. However, this information is shared in DNS servers on the Internet in general, so if the servers went down (heaven forbid), then the main thing that would be affected is that no DNS changes would occur until the servers (specifically the InMotion DNS servers) came back up. An example of a DNS change is like changing the MX records you're referring to. Once a change is made, it is propagated on the internet. In regards to your MX records, email would still flow if you're already pointed to Google Apps - unless Google's servers went down - which probably won't happen. Bottomline, if you want your email to be handled by a third party such as Google Apps, then email would still work if an outage occurred at the InMotion servers.

I hope this helps to answer your question, please let us know if you require any further assistance.

Regards,
Arnel C.
n/a Points
2017-01-29 8:15 am

i recently decided to let inmotion host my wordpress site while using godaddy's workspace email to handle my emails. btw domain is hosted at godaddy.

from my godaddy control panel i changed my nameservers to ns1.inmotionhosting.com and ns2.inmotionhosting.com. then i went inside inmotionhostings cpanel->MX Entry and created 2 MX records to point to the nameservers responsible for godaddy's workspace email.

email works and goes into my godaddy workspace email inbox.

i realised that, contrary to what i read on these forums, I didn't have to create an A record called 'mail' and point it to godaddy, then create 2 MX records and point them to 'mail'. now why is this so?

Staff
43,209 Points
2017-01-30 4:06 pm
MX records must point to an A record. The mail record we suggest creating is an A record. The server names you are pointing to at GoDaddy are also A records. That is what matters.
